Unlock Materials, Applications & Features
| Technical Details | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Max. Capacity | Head | Solid handle size | Temperature | Impeller | Material | ||||||
| Up to 250 M3 / hr. Max. | Up to 30 mtrs | UUp to 40 mm | Up to 150 Deg. C | Semi Open/ OPEN | C.I., C.S., SS-304, SS-316, SS-304L, SS-316L, CD4MCU AND OTHER ALLOY MATERIAL | ||||||
| Material Construction | |||||||||||
| Casing | Impeller | Stuffing box | Shaft and Sleeve | Bearing housing | |||||||
| C.I., C.S., SS-304, SS-316, SS-304L, SS-316L, CD4MCU AND OTHER ALLOY MATERIAL | C.I., C.S., SS-304, SS-316, SS-304L, SS-316L, CD4MCU AND OTHER ALLOY MATERIAL | C.I., C.S., SS-304, SS-316, SS-304L, SS-316L, CD4MCU AND OTHER ALLOY MATERIAL | EN-8 , SS 410 , SS 304 , SS 316 | C.I., C.S., SS-304, SS-316, SS-304L, SS-316L | |||||||
| Applications | Features | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Chemical industries | Good solid handling capacity | ||||||||||
| ETP & STP plants | Dynamic balanced rotating parts | ||||||||||
| Oil & refinery industries | Oil and grease-lubricated bearings | ||||||||||
| Petrochemical industries | Heavy-duty shaft | ||||||||||
| Chemical plants | High efficiency and speed variability options | ||||||||||
| Waste water treatment plant | Easy maintenance | ||||||||||
